TG-5AU-PLUS+4-011J
QUANSHENG TG-5A PLUS UHF 400-470MHZ
Description:
- CTCSS/DCS function
-Scan function
-Dual-watch operation
-Reminder after transmitting
-H/L output power selective
-200 channels
-PC programmable
-Channel name edit
-Busy channel lock(BCLO)
-VOX
Specifications:
|
Item name
|
TG5AU-PLUS
|
|
General
|
|
Frequency Range
|
400-470MHz
|
|
UHF
|
|
Frequency stability
|
5ppm
|
|
Channel No.
|
200
|
|
Antenna Impedance
|
50Ω
|
|
Loudspeaker Impedance
|
4Ω
|
|
Dimension（H x W x D）
|
80 X 50 X 30mm
|
|
Weight
|
509g（including battery, antenna）
|
|
Transmitter
|
|
Output power
|
5W
|
|
Modulation Mode
|
16KΦF3E
|
|
Maximum deviation
|
≤5.0KHz
|
|
Remnant Radiation
|
≤7μW
|
|
Audio Characteristics
|
≤6dB/ per fold
|
|
Adjacent Channel Function
|
65dB
|
|
Emission Current
|
≤1.4 A(H)
|
|
CTCSS/DCS Frequency Deviation
|
0.75KHz
|
|
Modulation Selectivity
|
12mV
|
|
Modulation distortion
|
≤ 5%
|
|
Receiver
|
|
RF Sensitivity
|
-121 dB (12 dB SINAD)
|
|
Receiver Bandwidth
|
5KHz (W)
|
|
Audio Frequency Power
|
0.25W
|
|
Audio Distortion
|
≤10
|
|
Blocking
|
85 dB
|
**本機語言是英語設定，無法轉為中文
***所有貨品更改規格,或與說明書不乎,不另外通知,以收貨標準為準.
Photo will have chromatic aberration compared with the product
- 1 x QUANSHENG TG5AU-PLUS Radio (UHF 400-470MHZ)
- 1 x 7.2V 1500mah Li-ion Battery Pack
- 1 x Dual band Antenna
- 1 x Belt Clip
- 1 x ENG Manual
- 1 x Desktop Charger ( 100V ~ 240V )+(2pin USA or 3pin UK or 2pin EURO or 2pin Australia)
