TG-UV2 x10+1x 1020-0002

10x QUANSHENG TGUV2 Dual Band

(VHF 136-174Mhz and UHF 400-470MHZ)

+ 1x LIGHT JACKET

(please choose the LIGHT JACKET Size)

• U-U, V-V, U-V work mode
  • Voice scrambler (Optional)
    • CTCSS/DCS auto search
      • Built-in Vox function
        • FM radio
          • Jacklight function
            • Alpha-numeric display
              • Talk in multi-bands
                • PC programmable
                  • 1750Hz call tone
                    • Frequency/channel scanning
                      • Channel scanning list edition(by which you may choose a channel to scan)
                        • Battery : Li-ion battery
                          • Dual-watch operation
                            • Power switch:5w/2.5w/1w
                              • Priority scan
                                • Wide/narrow bandwidth
                                  • Transmitter:
                                    • Power output: High≥5w Medium ≥2.5w Low ≥1w
                                      • Emission Current: ≤1.5A
                                        • Modulation sensitivity: 12mV
                                          • Modulation Distortion: <5%
                                            • Modulation Limiting : Wide <5KHz Narrow <2.5KHz
                                              • Modulation Mode: 16ΦF3E 11KΦF3E
                                                • Remanent Radiation ≤7μw
                                                  • Preemphasis character : 6dB
                                                    • CTCSS/DCS Frequency Deviation :0.75KHz±50Hz 0.37KHz±30Hz
                                                    • Receiver:
                                                      • RF Sensitivity: -122dBm(12dB SINAD)
                                                        • Modulation Receiver Bandwith: 5KHz
                                                          • Audio Distortion: ≤10%
                                                            • Audio power: <0.5w
                                                              • Audio Response:6dB
                                                                • Blocking: ≥85dB
                                                                  • Spurious response rejection: ≥65db
                                                                  • Dimensions: 110mmx 56mmx 37mm
                                                                  Free For
                                                                  LIGHT JACKET
                                                                  (please choose the LIGHT JACKET Size)





                                                                  Free For















                                                                  	S	M	L	XL	XXL
                                                                  胸圍	44吋(inch)	46吋(inch)	48吋(inch)	50吋(inch)	52吋(inch)
                                                                  腳圍	42吋(inch)	44吋(inch)	46吋(inch)	48吋(inch)	50吋(inch)
                                                                  衫長	27吋(inch)	28吋(inch)	29吋(inch)	30吋(inch)	31吋(inch)
                                                                  袖長(領邊量)	29吋(inch)	30吋(inch)	31吋(inch)	32吋(inch)	33吋(inch)

















                                                                  Each Set PACKAGE CONTAIN 10 x Quansheng Dual Band radio TG-UV2 (VHF 136-174Mhz and UHF 400-470MHZ) 10 x 7.4V 2000mah Li-ion Battery Pack 10 x Dual band Antenna. 10 x Belt Clip. 10 x ENG Manual 10 x Desktop Charger ( 100V ~ 240V )+(2pin USA or 3pin UK or 2pin EURO or 2pin Australia) 10 x Earpiece with PTT 1 x LIGHT JACKET 1020-0002 (please choose the LIGHT JACKET Size) C * This model without Voice scrambler
